A RxJava based library using native code to convert images to Lowpoly

RxLowpoly

An Android library to bring your ordinary photos to life with an awesome crystallized effect.

Introduction

RxLowpoly serves as an improvement over XLowPoly by

fixing out of memory crashes by scaling down the image in a
loss-less manner before processing.
providing better quality results by using 4000 as the point count
by default which provides a good trade-off between speed and time.
the higher point count leads to a longer execution period, but it is
significantly reduced by scaling down the image before processing.
provides wider choice of input sources like Bitmap, File, Uri
or Drawable resource.
natively using RxJava for background processing thereby reducing
boilerplate code on the developer's end.

Lowpoly Samples

Original Image	Lowpoly Image

Installation

Add the dependency in your app module's build.gradle file

dependencies {
	...
        implementation "com.zebrostudio.rxlowpoly:rxlowpoly:{latest_version}"
}

That's it!

Library Details

RxLowpoly uses JNI with 64 bit support to meet google
specified requirement for all apps to be 64 bit enabled by August
2019.
Use of JNI enables much faster execution than other similar libraries.
Use of Sobel Operator for edge detection.
Use of Delaunay Triangulation on the
result from the sobel operator to construct the final crystallized
lowpoly effect on the image.

JNI

RxLowpoly uses the Java Native Interface to run native code written in C which provides much faster processing for edge detection using the Sobel Operator and then implementing the Delaunay Triangulation algorithm.

Sobel Operator

The Sobel Edge Detector is a gradient based edge detection algorithm which provides us with separate planes on which the Delaunay Triangulation can be applied.

Delaunay Triangulation

We take a set P of discrete points on an image plane and apply Delaunay
Triangulation DT(P) to produce triangles connecting 3 points at
a time such that no point in **P **is inside the circum-circle of any
triangle in DT(P). These separate triangles taken together in-turn
provide us with the image having a crystallized effect.

Which leads to the resultant crystallized image as :-

Usage Examples

Asynchronous call

The most simple use case is :-
```
  RxLowpoly.with(context)
      .input(bitmap)
      .generateAsync()
```
Along with Bitmaps we can also use Drawables or Files or Uri
as input.

When we need to downscale the image :-

 RxLowpoly.with(context)
     .input(bitmap)
     .overrideScaling(downScalingFactor)
     .generateAsync()

When we need to set a maximum width for the image :-

 RxLowpoly.with(context)
     .input(bitmap)
     .overrideScaling(maxWidth)
     .generateAsync()

We can also set a quality for the lowpoly image :-

 RxLowpoly.with(context)
     .input(inputUri)
     .overrideScaling(downScalingFactor)
     .quality(Quality.HIGH)
     .generateAsync()

VERY_HIGH, MEDIUM, LOW and VERY_LOW are also available as
Quality configurations

To save the lowpoly image to a file :-

 RxLowpoly.with(context)
     .input(inputUri)
     .overrideScaling(downScalingFactor)
     .quality(Quality.HIGH)
     .output(outputFile) // An Uri of a File is also supported as an output destination
     .generateAsync()

All asynchronous operation is done on the IO scheduler.

Synchronous call

Replacing generateAsync() with generate() in each of the Asynchronous call examples leads to a synchronous call with a lowpoly Bitmap as a result.

A Bitmap of the generated lowpoly image is always returned irrespective of synchronous or asynchronous calls and whether an output File or Uri is supplied using the output method.

Note : A full implementation can be found in the app module of this repository or in the open sourced WallR app.

Critical Analysis

The following tests have been performed on a Xiaomi Redmi Note 5 Pro with 6 gb Ram.

Input Source	Quality	Execution Time (ms)
Bitmap	Very High	15813
Drawable	Very High	16275
File	Very High	15987
Uri	Very High	15931
Bitmap	High	4547
Drawable	High	5088
File	High	4734
Uri	High	4612
Bitmap	Medium	1113
Drawable	Medium	1672
File	Medium	1297
Uri	Medium	1152
Bitmap	Low	918
Drawable	Low	1496
File	Low	1091
Uri	Low	996
Bitmap	Very Low	850
Drawable	Very Low	1024
File	Very Low	923
Uri	Very Low	876

Thus it is evident that when quality is set to High, a good trade-off between speed and texture is obtained, hence the default value of Quality is set to HIGH.

Also, we can see that Bitmap is the input format of choice as it is processed the fastest, followed by Uri, File and Drawable respectively.

Sample App

The sample app provides an implementation of various configurations of RxLowpoly which one can experience and assess first hand before using the library.
